H4-2000
4 Channel 2000W 8ohms Amplifier
Features

1. Rated Output Power 8Ω/Stereo: 4×2000W
2. Rated Output Power 4Ω/Stereo: 4×3400W
3. Rated Output Power 2Ω/Stereo: 4×4760W
4. Rated Output Power 16Ω/Bridge: 2×4000W
5. Rated Output Power 8Ω/Bridge: 2×6800W
6. Rated Output Power 4Ω/Bridge: 2×11560W
7. Output RMS voltage: 126.5V
8. Slew rate: 50V/us
9. Gain: Selectable:41dB,38dB,35dB,32dB
10. THD+N: 0.01%
11. IMD-SMPTE: 0.01%
12. DIM30: 0.01%
13. Cross-talk: ≥90 dB
14. Frequency Response: ±0.2dB
15. Input impedance: 20kΩ(balance) ,10kΩ(unbalance)
16. Damp factor(8Ω,20Hz-200Hz): ≥5000
17. SNR(A weighted 20Hz-22kHz): ≥112dB
18. Main power: 90~260VAC,50~60 Hz
19. Protection: Under voltage, DC, Over temperature, Over load limiter, Short protection
20. Size(W×H×D): 483×44×465mm
21. Net Weight: 13kg
